Machine Configuration Instructions:

1. Siemens computer  programmable  logic controller (PLC) in Germany,  large capacity input and output.

2. Siemens 10-inch color human-machine interface touch screen in Germany.

3.  1.5KW German Siemens servo system control,  high speed and  high  precision step walking speed.

4. Taiwan TYC laminated chain.

5. Imported electrical appliances (Bonne color-coded sensor, Schneider contactor, relay, push-button  switch,  power  protector,  Yangming  solid-state   relay,  Omron   proximity switch, etc.).

6. The pneumatic part adopts the valve island pneumatic system of Taiwan Yadeke.

7. Germany Liqile 202 vacuum pump, the highest vacuum degree of the vacuum pump reaches 0.1 millibar.

8. Import the American Bona photoelectric tracking system and use color cover film to ensure the alignment of the pattern.

9. The whole machine adopts 304 stainless steel frame, national standard 6MM, high strength, strong corrosion resistance, not easy to deform.

10. The upper and lower membranes adopt a new film walking system.

11.Forming, sealing and lifting are adopted by pneumatic lever independent lifting

self-locking system.

The equipment has precise front and rear positioning.

 The cross cutting knife works independently with centralized control by computer

14. Equipped with advanced waste collection device.

15. The lifting sliding bearing adopts non-lubricating graphite copper sleeve.

16. The forming, sealing, transverse and longitudinal parts are all equipped with safety protection system and protective cover.

17. The equipment is equipped with power phase shortage, reverse phase, high or low voltage, mechanical regular lubrication and other warning or protection systems, which are convenient for operators to use and adjust. In case of failure, the equipment will automatically stop and protect, and the computer will display the cause of the fault and the treatment.

③ Machine Advantages:

 The whole machine control system:

①  The  control  system  of  the  stretch  film  packaging  machine  fully  adopts  Siemens electrical  control  systems,  while  the  automatic  mold-changing  device  utilizes  Xinjie Electric Control  System. The  unified  brand  ensures  communication  sensitivity  among components. The Siemens industrial computer system independently possesses temperature  and  vacuum  detection  capabilities  with  automatic  fault  detection  functions. Featuring Siemens' most advanced high-inertia 2KW servo motors and high-precision servo drives, this system delivers robust operational torque performance The chain can be positioned accurately, fast and run smoothly.

②  High  and  low  voltage  control  appliances  are  made  by  the  world  famous  French Schneider Electric, which has more perfect control functions, more stable quality, faster processing speed and faster cycle reading period.

③  The  equipment  optimizes  the  cursor  tracking  system.  When  there  are  three consecutive failures of cursor tracking during operation, the system will automatically alarm and stop, effectively avoiding losses caused by misalignment of cursor.

Ⅱ, Steel frame structure:

①  One  stamping  molding,  high  structural  strength,  corrosion  resistance,  each  fixing position screw hole is processed by high precision laser once, to ensure the precision of assembly of each part, resulting in smooth operation of the whole machine.

②  Stainless  steel  frame  has  strong  resilience,  which  is  not  easy  to  deform  during transportation   or   machine   operation   and   better   maintains   the   integrity   of   the equipment.

III、 Integral four-rod linkage lifting device:

① The lifting mechanism is precision-engineered from 6061 aviation-grade aluminum alloy, ensuring precise component alignment and enhanced interchangeability while boosting  structural  stability.  The vertical  movement  system  utilizes  imported  high- wear-resistant linear bearings that deliver pinpoint positioning and smooth operation, enabling...

② The graphite copper sleeve is embedded at the joint of each linkage component to increase  lubrication,  reduce  wear  and  tear,  and  extend  service  life.  Moreover,  the graphite copper sleeve has the characteristics of high precision, small gap and high pressure  resistance,  which  fully  guarantees  the  sealing  of  molding  chamber  and vacuum chamber.

Ⅳ, Forming device

The  molding  part  adopts  positive  pressure  molding,  which   does  not  occupy  the equipment vacuum pump. The concave and convex surface electric heating plate is used to  ensure  uniform  film  molding  and  uniform  thickness  of  the  four  corners  of  the molding.

Ⅴ、 autovac

The vacuum part is joined with the electronic vacuum detection system to ensure that each product out of the vacuum chamber reaches the set vacuum value. If there is a phenomenon such as poor vacuum sealing (the sealing ring ages after a long time), the screen display fault will occur.

Ⅵ, Waste film collection device

The waste film collection device adopts intelligent detection device, which is noiseless, simple and beautiful appearance, the total power consumption is only 0.18kw/hour, and can automatically adjust the operation state according to the length of waste film.

Ⅶ、 security guard

① The equipment features temperature-sensitive components. Protective mechanisms with  magnetic  sensors  are   installed  on  all  cutting  and   moving  parts.  The   system automatically activates shutdown protocols when protective devices fail to meet safety requirements or are not properly configured, while maintaining operational status data. Upon proper repositioning of protective devices, the equipment resumes processing for subsequent cycles.
